Lap Joint Flanges (LJ Flanges) are used on piping fitted with lapped pipe or with lap joint stub ends the combined initial cost of the two items being approximately one-third higher than that of comparable welding neck flanges.

Lap joint flange is having two components, a stub end, and a loose backing flange. Stub end is butt welded to the pipe and Backing flange freely move over the pipe. The backing flange can be of different material than stub material and normally of the carbon steel to save the cost. Lap flange is used where frequent dismantling is required, and space is constrained.

Features:
254 SMO is a high performance austenitic stainless steel. Its high alloying elements content imparts excellent resistance to uniform, pitting and crevice corrosion, and stress corrosion cracking. It was originally developed to withstand the corrosion of acids, especially in the presence of halide ions, such as hydrochloric acid, hydrofluoric acid, phosphoric acid, and sulphuric acid contaminated with chlorides. In certain environments it is an alternative to more expensive nickel alloys and titanium alloys.

Applications:

Chemical processing equipment, pulp and paper industry bleaching equipment, desalination plant seawater piping, food and beverage industry, pharmaceuticals, and hydrometallurgy.

GRADES:

CHEMICAL COMPOSITION:

PHYSICAL PROPERTIES:
